2.Sit-down operation,comfortable and safe.
| Characteristics | |||
| 1.1 | Manufacturer | HYTGER | |
| 1.2 | Model designation | QDD60 | |
| 1.3 | Drive unit | Battery | |
| 1.4 | Operator type | Rider seated | |
| 1.5 | Load capacity | Q (kg) | 6000 |
| 1.7 | Rated drawbar pull | F (N) | 1200 |
| 1.9 | Wheelbase | y (mm) | 1130 |
| Weights | |||
| 2.1 | Service weight | kg | 1150 |
| 2.3 | Axle loading, unladen front/ rear | kg | 500/ 650 |
| Wheels, Chassis | |||
| 3.1 | Tyre type | Pneumatic | |
| 3.2 | Tyre size, front | 4.00-8 | |
| 3.3 | Tyre size, rear | 4.00-8 | |
| 3.5 | Wheels, number front/ rear (x=drive wheels) | 1/ 2x | |
| 3.7 | Tread, rear | b11 (mm) | 860 |
| Dimensions | |||
| 4.7 | Height of overhead guard (cabin) | h6 (mm) | 1300 |
| 4.8 | Seat height | h7 (mm) | 920 |
| 4.12 | Tow coupling height | h10a/b (mm) | 285/365 (235/315,340/420) |
| 4.13 | Platform height unladen | h11 (mm) | 770 |
| 4.16 | Loading platform, length | l3 (mm) | 370 |
| 4.17 | Rear overhang | l5 (mm) | 345 |
| 4.18 | Loading platform, width | b9 (mm) | 700 |
| 4.19 | Overall length | l1 (mm) | 1900 |
| 4.21 | Overall width | b1/ b2 (mm) | 990/990 |
| 4.32 | Ground clearance, center of wheelbase | m2 (mm) | 150 |
| 4.35 | Outer turning radius | Wa (mm) | 1850 |
| 4.36 | Inner turing radius | b13 (mm) | 600 |
| Performance | |||
| 5.1 | Travel speed, laden/ unladen | km/ h | 7/17 |
| 5.5 | Drawbar pull, laden/ unladen S2 60 min. | N | 1200 |
| 5.6 | Maximum drawbar pull, laden/ unladen S2 5 min. | N | 4500 |
| 5.8 | Maximum gradeability, laden/ unladen S2 5 min. | % | 5/20 |
| 5.10 | Service brake | Hydraulic/ Mechanical | |
| Drive | |||
| 6.1 | Drive motor rating S2 60 min. | kW | 4 |
| 6.4 | Battery voltage/ rated capacity (5h) | V/ Ah | 48/ 275 |
| 6.5 | Battery weight | kg | 540 |
| Battery dimensions l/ w/ h | mm | —— | |
| Others | |||
| 8.1 | Type of drive control | AC | |
| Manufacturer | ZAPI | ||
| 8.4 | Sound level at operator's ear | dB (A) | 70 |
| 8.5 | Tow coupling | PIN | |
