Wide view mast,Cyclone air cleaner,Load one-way value,Preheat indictor,King Pin,Engine-start switch,Standard backrest,Long-life tires,Overhead guard,Oil and water separator,Power steering,Adjustable steering column,Radiator water tank,Side roller,Standard carriage.Oil temperature cooler,Headlamp and steering indicator lamp,Charge indicator lamp,Hour meter,Oil warning light of engine.Water temperature guage,Fuel gauge,Reversing light,Electric horn,Neutral-safety switch,Rear mirrir,Tools,Reversing Buzzer,General seat.
Options:
Fire extingulsher,cab,Heater unit,Rear work light,Solid tires,Fireproof sliencer,Upper exhaust pipe,Tilt cylinder jacket,Rotating warning light,LPG conversion device,Pre-filtration air intake device.
Attachments:
Side shifter,Fork positioner,Carpet boom,Fork extension,Longer forks,Clamps,Others.
Features:
1.Cleaner,more efficient engines
2.Esay maintenance
3.Easier entry and exit form an extra-wide step
| STANDARD SPECIFICATION | ||||||
|---|---|---|---|---|---|---|
| General | 1 | Model | FG45T/C | |||
| 2 | Power Type | Gasoline(LPG) | ||||
| 3 | Rated Capacity | kg | 4500 | |||
| 4 | Load Centre | mm | 600 | |||
| Characteristic & Dimension | 5 | Lift Height | mm | |||
| 6 | Fork Size | L×W×T | mm | 1220×150×50 | ||
| 7 | Mast Tilt Angle | F/R | Deg | |||
| 8 | Front Overhang (Wheel center to fork face) | mm | 560 | |||
| 9 | Ground Clearance (Bottom of mast) | mm | 100 | |||
| 10 | Overall Dimension | Length to face of fork (Without fork) | mm | 3100 | ||
| 11 | Overall Width | mm | 1485 | |||
| 12 | Mast Lowered Height | mm | 2300 | |||
| 13 | Mast Extended Height (With backrest) | mm | 4266 | |||
| 14 | Overhead Guard Height | mm | 2270 | |||
| 15 | Turning Radius (Outside) | mm | 2780 | |||
| Performance | 16 | Speed | Travel (Full load) | km/h | 18/19 | |
| 17 | Lifting (Full load) | mm/s | 410/430 | |||
| 18 | Tire | Front | 300-15-18PR | |||
| Power&Transmission | 19 | Rear | 7.00-12-12PR | |||
| 20 | Wheelbase | mm | 2000 | |||
| 21 | Service Weight | kg | 7230 | |||
| 22 | Engine | Model | U.S Engine GM4.3 | |||
| 23 | Manufacture | U.S | ||||
| 24 | Rated Output | kw/rpm | 57/2200 | |||
| 25 | Rated Torque | N·m/rpm | 297/1600 | |||
| 26 | No. of Cylinder | 4 | ||||
| 27 | Displacement | cc | 4578 | |||
| 28 | Fuel Tank Capacity | L | 70 | |||
| 29 | Transmission | Type | T means Torque Converter, C means Clutch | |||
| 30 | Stage | F/R | 1/1(2/2) | |||
