2.The internal gantry is independent posts and connected to the fork with bolts.The piston rod moves up and down to elevate and descend the goods,without the help of the roller board to transmit. The external post is the supporting post,welded to the rack platform,which reduces the total height and weight.
3.The gate base is unfixed which allows a relative motion with the elevating of the rack and fork.When the fork(including the goods) rises to the platform height,the gate base withdraws and the rack rises to the platform with the cylinder in circulation.
| Item | Unit | SDYG-Z-0511 | SDYG-Z-0513 |
| Capacity | kg | 500 | 350 |
| Load center | mm | 400 | 400 |
| Wheelbase | mm | 860 | 860 |
| Front Wheel Distance | mm | 380 | 380 |
| Rear track | mm | 670 | 670 |
| Min.Fork Height | mm | 90 | 90 |
| Max.Fork Height | mm | 1100 | 1300 |
| Height of frame(fork down) | mm | 1400 | 1600 |
| The lifting height of the whole(after tape file) | mm | 2700 | 2900 |
| Min. Rught Abgle Channel Width | mm | 1150 | 1150 |
| Steering Rear Wheel | mm | ф100*50 | ф100*50 |
| Loading Wheel | mm | ф70*60 | ф70*60 |
| Guide wheel | mm | ф40*26/ф30*26 | ф40*26/ф30*26 |
| Overall length | mm | 1600 | 1600 |
| Overall width | mm | 780 | 780 |
| Fork Size | l/e/s | 1150*155*60 | 1150*155*60 |
| Fork Width | mm | 535 | 535 |
| Turning Radius | mm | 1100 | 1120 |
| Lifting Speed | mm/s | 80 | 80 |
| Descent Speed | mm/s | 90 | 90 |
| Lifting motor Power | kw | 12V/0.8 | 12V/0.8 |
| Battery | V/Ah | 12V/33Ah | 12V/33Ah |
| Type of Driving | Pedestrian | Pedestrian | |
| Material of wheel | Nylon/PU | Nylon/PU | |
| Net weight | kg | 197 | 219 |
