2.Mantenance-free AC driving motor offers stronger power,making it more cost-effective;
3.Slowing-dwon in curved pathway ensures the smoothness and stability.
| Characteristics | |||||
| 1.1 | Manufacturer | HYTGER | HYTGER | HYTGER | |
| 1.2 | Model designation | QDD30 | QDD45 | QDD45E | |
| 1.3 | Drive unit | Battery | Battery | Battery | |
| 1.4 | Operator type | Rider seated | Rider seated | Rider seated | |
| 1.5 | Load capacity | Q (kg) | 3000 | 4500 | 4500 |
| 1.7 | Rated drawbar pull | F (N) | 600 | 900 | 900 |
| 1.9 | Wheelbase | y (mm) | 850 | 950 | 950 |
| Weights | |||||
| 2.1 | Service weight | kg | 700 | 800 | 810 |
| Wheels, Chassis | |||||
| 3.1 | Tyre type | Pneumatic | Pneumatic | Pneumatic | |
| 3.2 | Tyre size, front | Ф230x75 | Ф260x95 | Ф260x95 | |
| 3.3 | Tyre size, rear | 2x Ф178x73 | 2x Ф178x73 | 2x Ф178x73 | |
| 3.5 | Wheels, number front/ rear (x=drive wheels) | 1x+ 2/2 | 1x+ 2/2 | 1x+ 2/2 | |
| 3.7 | Tread, rear | b11 (mm) | 777 | 777 | 777 |
| Dimensions | |||||
| 4.7 | Height of overhead guard (cabin) | h6 (mm) | 1444 | 1560 | 1560 |
| 4.12 | Tow coupling height | h10a/b (mm) | 188/233/277/322 | 188/233/277/322 | 188/233/277/322 |
| 4.19 | Overall length | l1 (mm) | 1284 | 1430 | 1430 |
| 4.21 | Overall width | b1/ b2 (mm) | 850 | 850 | 850 |
| 4.32 | Ground clearance | m2 (mm) | 90 | 90 | 90 |
| 4.35 | Outer turning radius | Wa (mm) | 1047 | 1196 | 1196 |
| Performance | |||||
| 5.1 | Travel speed, laden/ unladen | km/ h | 5/7 | 7/12.5 | 7/12.5 |
| 5.5 | Drawbar pull, laden/ unladen S2 60 min. | N | 600 | 900 | 900 |
| 5.6 | Maximum drawbar pull, laden/ unladen S2 5 min. | N | 1800 | 2600 | 2600 |
| 5.8 | Maximum gradeability, laden/ unladen S2 5 min. | % | 3/15 | 3/15 | 3/15 |
| 5.10 | Service brake | Electromagnetic | Electromagnetic | Electromagnetic | |
| Drive | |||||
| 6.1 | Drive motor rating S2 60 min. | kW | 1.5 | 4 | 4 |
| 6.4 | Battery voltage/ rated capacity (5h) | V/ Ah | 24/210 | 24/280 | 24/280 |
| 6.5 | Battery weight | kg | 190 | 250 | 250 |
| Others | |||||
| 8.1 | Type of drive control | AC ZAPI | AC ZAPI | AC ZAPI | |
| 8.4 | Sound level at operator's ear | dB (A) | 70 | 70 | 70 |
| 8.5 | Tow coupling | PIN | PIN | PIN | |
