2.High strength vertical gearbox,longer working life.
3.Low-noise and durable hydraulic unit,high quality cylinder as well as hose ensure the high reliability of hydraulic system.
4.AMP cnnecter and durable electric wires and cables,greatly reducing electric parts failure rate.
5.Super high intensity frame design supports high speed,high capacity and long distance applications.
6.Adjustable long push rod ensures the stability and lifespan of the truck.
| Characteristics | ||||
| 1.1 | Manufacturer | HYTGER | ||
| 1.2 | Model designation | EPT20-30RT（S） | EPT20-35RT（S） | |
| 1.3 | Model designation | Battery | Battery | |
| 1.4 | Drive unit | Ride | Ride | |
| 1.5 | Load capacity | Q (kg) | 3000 | 3500 |
| 1.6 | Load center | c (mm) | 600 | 600 |
| 1.8 | Load distance (Raised/ Lowered) | x (mm) | 920 | 920 |
| 1.9 | Wheelbase | y (mm) | 1722 | 1722 |
| Weights | ||||
| 2.1 | Service weight (Incl. battery) | kg | 810 | 1040 |
| Wheels, Chassis | ||||
| 3.1 | Tyre type，operator side/ load side | PU/PU | PU/PU | |
| 3.2 | Tyre size, operator side | Ф254X95 | Ф254X95 | |
| 3.3 | Tyre size, load side | Ф82.5X165 | Ф82.5X165 | |
| 3.4 | Balance wheels (dimensions) | Ф100X63.5 | Ф100X63.5 | |
| 3.5 | Wheels, number operator/load side (x=drive wheels) | 1/2/2 | 1/2/2 | |
| 3.6 | Tread, operator side | b10 (mm) | 668 | 668 |
| 3.7 | Tread, load side | b11 (mm) | 456 | 456 |
| Dimensions | ||||
| 4.4 | Lift height | h3 (mm) | 140 | 140 |
| 4.9 | Height of tiller arm in operating position, min/ max | h14 (mm) | 1117/1646 | 1117/1646 |
| 4.15 | Fork height, lowered | h13 (mm) | 82.5 | 82.5 |
| 4.19 | Overall length | l1 (mm) | 2355 | 3563 |
| 4.20 | Length to face of forks | l2 (mm) | 1135 | 1135 |
| 4.21 | Overall width | b1/ b2 (mm) | 915 | 915 |
| 4.22 | Fork dimensions | s/ e/ l (mm) | 60/230/1190 | 60/230/1190 |
| 4.25 | Fork spread, min/ max | b5 (mm) | 685 | 710 |
| 4.33 | Aisle width, 1000×1200 pallet crossways | Ast (mm) | 2555 | 3765 |
| 4.35 | Outer turning radius | Wa (mm) | 2064 | 2590 |
| Performance | ||||
| 5.1 | Travel speed, laden/ unladen | km/ h | 10.5/14.5 | 10.5/14.5 |
| 5.2 | Lifting speed, laden/ unladen | m/ s | 0.03/0.033 | 0.028/0.03333 |
| 5.3 | Lowering speed, laden/ unladen | m/ s | 0.040/0.038 | 0.040/0.038 |
| 5.8 | Maximum gradeability, laden/ unladen S2 5 min. | % | 8/15 | 6/15 |
| 5.10 | Service brake | Electromagnetic | Electromagnetic | |
| Drive | ||||
| 6.1 | Drive motor rating S2 60 min. | kW | 4 | 4 |
| 6.2 | Lift motor rating at S3 15% | kW | 2.2 | 2.2 |
| 6.4 | Battery voltage/ rated capacity (5h) | V/ Ah | 24/360 | 24/360 |
| Others | ||||
| 8.1 | Type of drive control | AC ZAPI | ||
| 8.4 | Sound level at operator's ear | dB (A) | 70 | |
