2.High strength vertical gearbox,longer working life.
3.Low-noise but durable hydraulic unit,good quality cylinder as well as hose ensure the high reliability of hydraulic system.
4.AMP cnnecter electric wires and cables,greatly reducing electric parts failure rate.
5.H shape mast channel mast improves the strength of the whole truck.
6.High strength chassis enhances the reliability and durability of the truck.
7.Innovative drive floating operation system(DFA) ensures the stability of th truck when steering at high speed.
| Characteristics | ||||
| 1.1 | Manufacturer | HYTGER | HYTGER | |
| 1.2 | Model designation | ES16-16RA | ES20-20RAS | |
| 1.3 | Drive unit | Battery | Battery | |
| 1.4 | Operator type | Rider stand | Rider stand | |
| 1.5 | Load capacity | Q (kg) | 1600 | 2000 |
| 1.6 | Load center | c (mm) | 600 | 600 |
| 1.8 | Load distance | x (mm) | 713 | 693 |
| 1.9 | Wheelbase | y (mm) | 1394 | 1394 |
| Weights | ||||
| 2.1 | Service weight (Incl. battery) | kg | 1400 | 1350 |
| 2.2 | Axle loading, laden operator/load side | kg | 940/ 2060 | 1100/2250 |
| 2.3 | Axle loading, unladen operator/load side | kg | 890/ 510 | 950/400 |
| Wheels, Chassis | ||||
| 3.1 | Tyre type | PU/ PU | PU/ PU | |
| 3.2 | Tyre size, operator side | mm | Ф230x75 | Ф230x75 |
| 3.3 | Tyre size, load side | mm | Ф85x70 | Ф85x70 |
| 3.4 | Balance wheels (dimensions) | Ф130x60 | Ф130x55 | |
| 3.5 | Wheels, number operator/load side (x=drive wheels) | 1x+ 2/ 4 | 1x+ 2/ 4 | |
| 3.6 | Tread, operator side | b10 (mm) | 634 | 634 |
| 3.7 | Tread, load side | b11 (mm) | 380 | 495(outside628) |
| Dimensions | ||||
| 4.2 | Height, mast lowered | h1 (mm) | 2019 | 2020 |
| 4.3 | Free lift | h2 (mm) | 100 | 100 |
| 4.4 | Lift height | h3 (mm) | 3000 | 3000 |
| 4.5 | Height, mast extended | h4 (mm) | 3529 | 3465 |
| 4.9 | Height of tiller arm in operating position, min/ max | h14 (mm) | 1007/ 1412 | 1150/1480 |
| 4.15 | Fork height, lowered | h13 (mm) | 85 | 88 |
| 4.19 | Overall length | l1 (mm) | 2003/ 2525 | 2003/ 2525 |
| 4.20 | Length to face of forks | l2 (mm) | 860 | 860 |
| 4.21 | Overall width | b1/ b2 (mm) | 850 | 1010 |
| 4.22 | Fork dimensions | s/ e/ l (mm) | 60/ 190/ 1150 | 45×100×1150 |
| 4.25 | Outside fork width, minimum/ maximum | b5 (mm) | 570 | 200/780 |
| 4.32 | Ground clearance | m2 (mm) | 30 | 28 |
| 4.33 | Aisle width, 1000×1200 pallet crossways | Ast (mm) | 2521 | 2610/2971 |
| 4.34 | Aisle width, 800×1200 pallet lengthways | Ast (mm) | 2454 | 2580/2941 |
| 4.35 | Outer turning radius | Wa (mm) | 1613 | 1738/2099 |
| Performance | ||||
| 5.1 | Travel speed, laden/ unladen | km/ h | 7.5/ 8.5 | 4.5/5.0 |
| 5.2 | Lifting speed, laden/ unladen | m/ s | 0.15/ 0.18 | 0.1/ 0.16 |
| 5.3 | Lowering speed, laden/ unladen | m/ s | 0.20/ 0.15 | 0.19/ 0.18 |
| 5.8 | Maximum gradeability, laden/ unladen S2 5 min. | % | 8/ 16 | 6/ 12 |
| 5.10 | Service brake | Electromagnetic | Electromagnetic | |
| Drive | ||||
| 6.1 | Drive motor rating S2 60 min. | kW | 1.5 | 1.6 |
| 6.2 | Lift motor rating at S3 15% | kW | 3 | 3 |
| 6.4 | Battery voltage/ rated capacity (5h) | V/ Ah | 24/ 280 | 24/ 280 |
| 6.5 | Battery weight (with box) | kg | 350 | 238 |
| Battery compartment dimensions l/ w/ h | mm | 815/ 222/ 630 | 815×208×630 | |
| Battery type | Industry battery | Industry battery | ||
| Others | ||||
| 8.1 | Type of drive control | AC | AC | |
| Manufacturer | CURTIS | ZAPI | ||
| 8.4 | Sound level at operator's ear | dB (A) | 74 | 74 |
