2.Strong power,easy work
3.Capacity 1.5 ton,solving all problems in goods transit
4.Comparing to hand pallet truck,more efficienct and convenient
5.High quality assembly makes the truck durable
6.Solid body frame
7.Easy to maintenance,60Ah bttery,free maintenance
8.Small size makes passing in narrow pathway easily
| Characteristics | |||
|---|---|---|---|
| 1.1 | Manufacturer | HYTGER | |
| 1.2 | Model designation | EPT20-15ET2 | |
| 1.3 | Drive unit | Battery | |
| 1.4 | Operator type | Walkie | |
| 1.5 | Load capacity | Q (kg) | 1500 |
| 1.6 | Load center | c (mm) | 600 |
| 1.8 | Load distance (Raised/ Lowered) | x (mm) | 889/946 |
| 1.9 | Wheelbase | y (mm) | 1261/1250 |
| Weights | |||
| 2.1 | Service weight (Incl. battery) | kg | 195 |
| 2.2 | Axle loading, laden operator/load side | kg | 565/1130 |
| 2.3 | Axle loading, unladen operator/load side | kg | 155/40 |
| Wheels, Chassis | |||
| 3.1 | Tyre type | PU/ PU | |
| 3.2 | Tyre size, operator side | Ф210x70 | |
| 3.3 | Tyre size, load side | 2xΦ78x60(Φ78x88) | |
| 3.5 | Wheels, number operator/load side (x=drive wheels) | 1x/4(1x/2) | |
| 3.7 | Tread, load side | 410(535) | |
| Dimensions | |||
| 4.4 | Lift height | h3 (mm) | 115 |
| 4.9 | Height of tiller arm in operating position, min/ max | h14 (mm) | 790/1225 |
| 4.15 | Fork height, lowered | h13 (mm) | 80 |
| 4.19 | Overall length | l1 (mm) | 1638 |
| 4.20 | Length to face of forks | l2 (mm) | 488 |
| 4.21 | Overall width | b1/ b2 (mm) | 568(685) |
| 4.22 | Fork dimensions | s/ e/ l (mm) | 55/ 150/ 1150 |
| 4.25 | Fork spread, min/ max | b5 (mm) | 568(685) |
| 4.32 | Ground clearance, center of wheelbase | m2 (mm) | 30 |
| 4.33 | Aisle width, 1000×1200 pallet crossways | Ast (mm) | 1739 |
| 4.34 | Aisle width, 800×1200 pallet lengthways | Ast (mm) | 1939 |
| 4.35 | Outer turning radius | Wa (mm) | 1485 |
| Performance | |||
| 5.1 | Travel speed, laden/ unladen | km/ h | 4/4.5 |
| 5.2 | Lifting speed, laden/ unladen | m/ s | 0.029/ 0.038 |
| 5.3 | Lowering speed, laden/ unladen | m/ s | 0.046/ 0.033 |
| 5.8 | Maximum gradeability, laden/ unladen S2 5 min. | % | 2/ 6 |
| 5.10 | Service brake | Electromagnetic | |
| Drive | |||
| 6.1 | Drive motor rating S2 60 min. | kW | 0.65 |
| 6.2 | Lift motor rating at S3 15% | kW | 0.84 |
| 6.4 | Battery voltage/ rated capacity (5h) | V/ Ah | 24/ 65 |
| 6.5 | Battery weight | kg | 22.5×2 |
| Others | |||
| 8.1 | Type of drive control | DC | |
| Manufacturer | CURTIS | ||
| 8.4 | Sound level at operator's ear | dB (A) | 74 |
