1.Micro-computer controlling of AC driving type
2.Wide view mast
3.Power steering
4.Neutral-safety switch
5.Regenerative braking
6.Big rubber pad
Optional parts
Tiresdouble tires(3ton),solid tires,environmental protection solid tires
Mast2 stage free lift mast(VFM),3 stage free lift mast(VFHM)
Attachments
Side shifter,Flat clamp,Paper roll clamp,Rotator,Multi-purpose clamp,Drum clamp,Carpet boom,Boom,Lifing hook,widen carriage,Fork extension.
Features
1.Yellow handle grip avoiding wrong operation
2.Comfortable foot-operation with coverboard and handing pedal
3.Easy up and down with lowering height
Advantages
1.AC variable frequency drive motor lowers the maintenance cost,improves sfficency and reduce the energy consumption at the same time.
2.By advanced America CURTIS inverter controller
| Characteristics | |||||||
|---|---|---|---|---|---|---|---|
| 1.1 | Manufacturer | HYTGER | HYTGER | HYTGER | HYTGER | HYTGER | |
| 1.2 | Model designation | CPD05TVE3 | CPD08TVE3 | CPD10TVE3 | CPD12TVE3 | CPD15TVE3 | |
| 1.3 | Drive unit | Battery | Battery | Battery | Battery | Battery | |
| 1.4 | Operator type | Rider seated | Rider seated | Rider seated | Rider seated | Rider seated | |
| 1.5 | Load capacity | Q (kg) | 500 | 800 | 1000 | 1200 | 1500 |
| 1.6 | Load center | c (mm) | 400 | 400 | 400 | 400 | 500 |
| 1.8 | Wheelbase | x (mm) | 182.5 | 182.5 | 182.5 | 243.5 | 183.5 |
| 1.9 | Load distance | y (mm) | 1070 | 1070 | 1070 | 1150 | 1295 |
| Weights | |||||||
| 2.1 | Service weight (Incl. battery) | kg | 1195 | 1475 | 1615 | 1940 | 2162 |
| 2.2 | Axle loading, loaded front/ rear | kg | 1420/275 | 1910/365 | 2195/420 | 2670/470 | 3106/556 |
| 2.3 | Axle loading, unloaded front/ rear | kg | 565/630 | 700/775 | 765/850 | 800/1140 | 801/1361 |
| Wheels, Chassis | |||||||
| 3.1 | Tyre type | PU | PU | PU | PU | PU | |
| 3.2 | Tyre size, operator side | 230/75 | 230/75 | 230/75 | 285/108 | 285/108 | |
| 3.3 | Tyre size, load side | 230/75 | 230/75 | 230/75 | 230/75 | 260/105 | |
| 3.5 | Wheels, number front/ rear (x=drive wheels) | 2/1 | 2/1 | 2/1 | 2/1 | 2/1 | |
| 3.6 | Tread, front | b10 (mm) | 830 | 830 | 830 | 830 | 910 |
| Dimensions | |||||||
| 4.2 | Height, mast lowered | h1 (mm) | 2060 | 2060 | 2060 | 1985 | 1985 |
| 4.3 | Free lift | h2 (mm) | —— | —— | —— | 120 | 120 |
| 4.4 | Lift height | h3 (mm) | 2950 | 2950 | 2950 | 2930 | 2930 |
| 4.5 | Height, mast extended | h4 (mm) | 3860 | 3860 | 3860 | 3845 | 3906 |
| 4.7 | Height of overhead guard (cabin) | h6 (mm) | 1980 | 1980 | 1980 | 1985 | 1985 |
| 4.8 | Seat height | h7 (mm) | 975 | 975 | 975 | 970 | 970 |
| 4.12 | Tow coupling height | h10 (mm) | —— | —— | —— | —— | —— |
| 4.19 | Overall length | l1 (mm) | 2350 | 2530 | 2530 | 2530 | 2620 |
| 4.2 | Length to face of forks | l2 (mm) | 1430 | 1430 | 1430 | 1610 | 1700 |
| 4.21 | Overall width | b1/ b2 (mm) | 944 | 944 | 944 | 948 | 1020 |
| 4.22 | Fork dimensions | s/ e/ l (mm) | 40×100×920 | 40×100×920 | 40×100×920 | 40×100×920 | 40×100×920 |
| 4.23 | Fork carriage type | A | A | A | A | A | |
| 4.24 | Fork carriage width | b3 (mm) | 720 | 720 | 720 | 800 | 720 |
| 4.31 | Ground clearance, loaded, below mast | m1 (mm) | 90 | 90 | 90 | 78 | 78 |
| 4.32 | Ground clearance, center of wheelbase | m2 (mm) | 95 | 95 | 95 | 95 | 95 |
| 4.33 | Aisle width, 1000×1200 pallet crossways | Ast (mm) | 2830 | 2830 | 2830 | 2975 | 3076 |
| 4.34 | Aisle width, 800×1200 pallet lengthways | Ast (mm) | 2945 | 2945 | 2945 | 3090 | 3189 |
| 4.35 | Outer turning radius | Wa (mm) | 1330 | 1330 | 1330 | 1450 | 1549 |
| Performance | |||||||
| 5.1 | Travel speed, loaded/ unloaded | km/ h | 6/8 | 6/8 | 6/8 | 6/8 | 6/8 |
| 5.2 | Lifting speed, loaded/ unloaded | m/ s | 0.13/0.2 | 0.13/0.2 | 0.13/0.2 | 0.12/0.2 | 0.11/0.2 |
| 5.3 | Reach speed，loaded/ unloaded | m/ s | 0.14/0.125 | 0.14/0.125 | 0.14/0.125 | 0.14/0.125 | 0.22/0.2 |
| 5.7 | Gradeability（loaded/unloaded） | % | 6/8 | 6/8 | 6/8 | 6/8 | 6/8 |
| 5.1 | Service brake | Hydraulic/mechanical | Hydraulic/mechanical | Hydraulic/mechanical | Hydraulic/mechanical | Hydraulic/mechanical | |
| Drive | |||||||
| 6.1 | Drive motor rating S2 60 min. | kW | 1.5 | 1.5 | 1.5 | 1.5 | 3.3 |
| 6.2 | Lift motor rating at S3 15% | kW | 2.2 | 2.2 | 3 | 3 | 4 |
| 6.4 | Battery voltage/ rated capacity | V/ Ah | 24/ 210 | 24/ 210 | 24/ 210 | 24/ 360 | 24/ 500 |
| 6.5 | Battery weight | kg | 210 | 210 | 210 | 360 | 500 |
| Others | |||||||
| 8.1 | Type of drive control | AC | AC | AC | AC | AC | |
| 8.4 | Sound level at operator's ear | dB (A) | 70 | 70 | 70 | 70 | 70 |
